PhantomRing is one of the Sherlock boxes on HackTheBox, which is their forensics/malware-analysis line rather than the usual “pop a shell” Machines. You get a zip, a short scenario, and a set of questions to answer from evidence in that zip. This one hands you a single Linux binary and asks you to figure out what it does without running it, since it’s a real (if simple) piece of post-exploitation malware.

Provided Files:

You get phantomring.zip, password protected (HTB gives you the password on the download page), containing one file:

phantom_ring/agent

The scenario is basically: a SOC team found this binary sitting in /var/tmp on a box, it was making outbound connections, and you need to work out what it’s capable of and pull out IOCs, all through static analysis.

Walk Through:

First thing, don’t run it. It’s live malware, so everything below is read-only inspection.

Basic triage

Once extracted, start with the boring stuff:

file phantom_ring/agent

phantom_ring/agent: ELF 64-bit LSB pie executable, x86-64, version 1 (SYSV),
dynamically linked, interpreter /lib64/ld-linux-x86-64.so.2,
BuildID[sha1]=<build id>,
for GNU/Linux 3.2.0, not stripped

Not stripped is the important bit here. That means the symbol table is still in the binary, so function names survive. Grab the hash while you’re at it since it’s usually one of the scored questions on these:

sha256sum phantom_ring/agent

Looking at the symbols before touching the disassembler

nm phantom_ring/agent | grep ' T \| t '

This lists every function name in the binary. Because it wasn’t stripped, you get real names instead of sub_401230-style garbage. Scanning through, a few things stand out immediately:

  • A block of local helper symbols that all share one distinctive name prefix (things like <prefix>_prep_read, <prefix>_wait_cqe, <prefix>_cq_advance), plus a couple of higher-level wrapper functions (a file reader, send_all, recv_all) built on top of them. That shared prefix names a specific Linux async I/O kernel interface, and every one of the agent’s own file and socket operations routes through it instead of libc’s classic read/write/connect/open wrappers. That’s the answer to “which kernel interface does it abuse for EDR evasion”, you just need to recognize the prefix and know why malware likes hiding behind that particular interface.
  • A run of cmd_* functions (things like cmd_get, cmd_recv, cmd_privesc, cmd_selfdestruct, and several more in the same style), plus process_cmd and main. That’s the command handler layout right there, one function per capability, and the exact count is worth writing down for later.

Worth flagging early: the number of cmd_* handler symbols here is not automatically the same as the number of distinct commands the dispatcher exposes to a connected client. That distinction matters later.

I used this list as a map for the rest of the analysis, jumping straight to whichever cmd_* function was relevant instead of reading the whole disassembly top to bottom.

Pulling strings

strings -n 4 phantom_ring/agent

This is always worth doing early since it’s free and this binary didn’t bother hiding anything. Scrolling through the output you get a good chunk of the picture right away:

  • A procfs-style path right next to "Logged users:" and its matching "Error reading ..." message. That’s the login-enumeration file cmd_users parses, a classic session-tracking table.
  • /proc, /proc/%ld/comm, /proc/%ld/fd, /dev/pts sitting near a "PID CMD" header, which is cmd_ps walking procfs to list processes.
  • A single directory path grouped with "Failed to open ..." and "Potential SUID binaries:". That’s the SUID scan directory in cmd_privesc, no ambiguity about which string it is, just not naming it here.
  • "Agent will self-destruct" and "Unlink failed: %s" bracketing a procfs path in cmd_selfdestruct. That path is what it reads to find its own location on disk before deleting itself.
  • Three /sys/kernel/debug/tracing/... paths back to back, plus "[*] Tracing disabled: %s". Three candidates for “first tracing file disabled”, but strings just dumps them in file order, it doesn’t tell you which one the code actually touches first.
  • /sys/fs/bpf, a /proc/%s/maps-style format string, a short marker string, and "[+] Killed PID using BPF: %d" clustered together, which is the eBPF/killbpf detection logic. The format string is what it builds per PID, the marker is the substring it hunts for inside that file. What strings alone doesn’t tell you is when in the loop that check runs relative to the tracing-file cleanup in the same handler.
  • A short run of two-to-eight character tokens right before the "[*] 404 Command not found [*]" message: these are the literal command names the dispatcher compares against, one of which triggers self-destruction.
  • One dotted-quad IPv4 address sitting completely alone in the string table, right next to the literal socket symbol name and one of the async-I/O helper symbols mentioned above. That’s the hardcoded C2 address, in the clear, no obfuscation attempted.
  • "connect() failed: trying to reconnect" and "[+] Connected to %s:%d" bracketing the connect logic.

What strings cannot give you: the port number, the reconnect delay, which of the three tracing paths is disabled first, which of the two procfs paths feeds the eBPF strstr check, and the true count of distinct commands. All five of those live only as numeric operands or control-flow order in the machine code, never as printable text. For those you have to read the disassembly.

Digging into the disassembly

objdump -d --no-show-raw-insn phantom_ring/agent > disasm.txt

First annoyance: this binary was built with the hardened PLT (.plt.sec), so objdump prints calls to it as a bare offset like callq 0x12c0 <.plt.sec+0x10> instead of a friendly name. Before reading anything else I resolved that table once so every later call site would be self-explanatory. .plt.sec is a block of 16-byte stubs starting at 0x12b0, each one doing endbr64 then jmpq *offset(%rip) into a GOT slot, and objdump -R prints exactly which imported symbol lives in each GOT slot:

objdump -R phantom_ring/agent

Lining up GOT addresses against stub addresses (stub base = GOT-slot-relative jump target minus 4 bytes for the endbr64) gives a lookup table, for example .plt.sec+0x10 is strncmp, +0x70 is strlen, +0x1c0 is readdir… once you have that table written down, every callq 0x12xx <.plt.sec+...> in the rest of the disassembly reads like a normal function call.

Port and reconnect delay. Inside main(), right before the connect sequence, there’s this:

41f7:  movw   $0x2, -0x10100(%rbp)
4200:  movl   $<port immediate>, %edi
4205:  callq  0x1350 <.plt.sec+0xa0>  ; htons
420a:  movw   %ax, -0x100fe(%rbp)

0x1350 resolves to htons in the PLT table. It’s called with a 16-bit immediate loaded straight into %edi, and the byte-swapped result gets written into the port field of the sockaddr struct sitting on the stack. That immediate, converted from hex to decimal, is the C2 port, and it’s a literal instruction operand, no guessing or dynamic computation involved.

Further down, on the failed-connect path right after the "connect() failed: trying to reconnect" string reference, there’s a movl $<delay immediate>, %edi immediately followed by a call into .plt.sec+0x230, which the PLT table resolves to sleep. That immediate, converted to decimal, is the reconnect back-off delay in seconds.

Command dispatch and the real count. process_cmd is a straight chain of length-checked strncmp/strcmp calls, each one comparing the sanitized input against one literal token before branching to a handler:

3ebf:  leaq   <offset>(%rip), %rcx   ; -> literal command token
3ecc:  callq  0x12c0 <.plt.sec+0x10>  ; strncmp
3ed3:  testl  %eax, %eax
3ed5:  jne    <next comparison>
...
3ee9:  callq  0x23da <cmd_get>

That pattern repeats once per candidate command, and every branch target is one of the cmd_* symbols from the nm output. Walking the whole chain and writing down (literal string, target handler) for each comparison is the only reliable way to build a full command inventory, and it’s what exposes the twist: one pair of literal tokens, a short one and a longer alias of it, both branch to the exact same callq target address. strings alone would never show you that, since it just lists both tokens as separate text with no idea they resolve to one implementation. The real “how many distinct commands” answer is the count of unique handler addresses actually called from this chain, not the count of literal strings sitting in .rodata, and those two counts are not equal here.

SUID scan and eBPF/tracing evasion. cmd_privesc calls one of the async-I/O prep helpers to stat a path, then opendir (.plt.sec+0x1c0) against a single hardcoded path loaded via leaq right before the call, no loop, no user input, one fixed directory. That’s the SUID scan directory, and there’s only one leaq feeding that opendir call so there’s nothing to disambiguate.

cmd_killbpf is denser. Near the top of the function it loads three pointers into a local array back to back:

37fb:  leaq  <offset 1>(%rip), %rax   ; -> tracing path
3802:  movq  %rax, -0x6130(%rbp)
3809:  leaq  <offset 2>(%rip), %rax   ; -> tracing path
3810:  movq  %rax, -0x6128(%rbp)
3817:  leaq  <offset 3>(%rip), %rax   ; -> tracing path
381e:  movq  %rax, -0x6120(%rbp)

Then it loops with an index starting at 0 (cmpl $0x2, %eax / jbe, so it runs for index 0, 1, 2), reading array[index] each pass and calling openat/write to flip it off. Array slot 0 is whichever leaq loaded first, at stack offset -0x6130(%rbp), so the first file it disables is whichever of the three tracing-file strings that first leaq points at, and that’s a fact about instruction order, not about which line strings happened to print first. I double-checked this against the raw .rodata bytes (see below) to make sure disassembly load order and on-disk string order actually agreed.

Later in the same function, after the tracing cleanup, it opens /proc, walks every PID directory with readdir, builds a per-PID path with snprintf using a format string, reads it through the higher-level async-I/O file reader mentioned earlier, and calls strstr against a second hardcoded string. That second string is the eBPF marker it’s hunting for inside the per-PID file, confirming the detection logic strings alone only hinted at, and pinning down exactly which of the two procfs-flavored strings from earlier is the format string versus the marker.

Self-destruct. cmd_selfdestruct calls readlink (.plt.sec+0x70) against a hardcoded procfs string, uses the resolved path in one of the async-I/O prep helpers to unlink the file, and only reaches that code path after process_cmd matched one specific literal token in the dispatch chain above, the same token that appears in the command inventory.

Confirming string order against raw bytes. RIP-relative leaq comments in disassembly are objdump’s own interpretation of what a load points at, not a guarantee. For the two things where exact order mattered (the tracing-file array and the command-token table), I cross-checked against the raw .rodata bytes directly:

objdump -s -j .rodata phantom_ring/agent

This dumps hex-plus-ASCII for the whole section. Reading the byte range each leaq comment pointed at and confirming it actually spells out the expected null-terminated string is what turned “the disassembler’s annotation says X” into “the bytes on disk are X”, a second, independent confirmation instead of trusting one tool’s guess.

What ties it together

Between file/sha256sum, nm, strings, and this focused pass through objdump -d plus the .rodata and relocation cross-checks, that covers all 12 scored items in this Sherlock: the hash, the C2 IP and port, the reconnect delay, the true command count (and the alias that causes the miscount if you’re not careful), the async-I/O evasion angle, the login-enumeration file, the process-listing path, the SUID scan directory, the eBPF detection string and the file it’s read from, the first tracing file disabled, the self-location path, and the self-destruct trigger string. None of the literal values themselves are reproduced here, run the same commands against your own extracted copy of the binary and they’ll fall out directly.

Analysis done entirely through static inspection (file, sha256sum, nm, objdump, strings). The binary was never executed.
