A virtual key is a per-caller credential your broker checks before it forwards a request to any backend. Give each agent and each person a separate key, attach rate limits, token and cost budgets, and a model allow-list, and one leaked or runaway caller stops at its own ceiling instead of draining your whole stack. This guide shows how to define those keys, read the exact refusal a blocked caller receives, and decide which limits belong on which key.

The guidance here maps to the governance layer of a local-first broker exposing one OpenAI-compatible endpoint. Every behavior below is backed by the broker’s own test suite unless marked otherwise.

Key Takeaways

  • Separate keys isolate blast radius. A compromised key spends only its own budget until you revoke it.
  • Budgets are fail-closed. A key with no token or cost headroom gets a 429, not a backend call.
  • Allow-lists bind the resolved model. A key scoped to chat never reaches a model outside its list, even through auto.
  • Aperture and the broker split the work. Aperture decides who reaches the endpoint. Broker keys decide what each caller spends and runs.
  • Keys live as hashes. A leaked keys file yields SHA-256 hashes, not working secrets.

Prerequisites

  • A running broker exposing one OpenAI-compatible endpoint in front of your backends. A companion article in this series covers the one-endpoint setup.
  • Admin access to the broker host to edit the keys file and reload the service.
  • One or more backends registered in the broker, such as a local runtime like Ollama or llama.cpp, or a hosted provider.

Estimated time: 30 to 45 minutes. Difficulty: intermediate. You edit a YAML file, mint keys, and read HTTP error envelopes. No code changes.

Who Reaches the Endpoint vs What a Key Spends

Two controls sit in front of your backends, and they answer different questions. Keeping them separate is the core of a safe local-first setup.

Tailscale Aperture is the private edge. It decides who reaches the broker at all. Callers arrive over your tailnet with a machine identity, and the broker binds locally instead of listening on a public port. This keeps the endpoint off the public internet. Aperture is a deployment property you configure at the network layer. The broker code does not enforce it, so treat the private edge as an operator responsibility.

Broker virtual keys are the governance layer. Once a caller reaches the endpoint, its key decides what the caller spends and which models it reaches. Rate limits, token and cost budgets, and the model allow-list all live on the key. This is the layer the rest of this article configures.

ControlQuestion it answersWhere it lives
Aperture private edgeWho reaches the brokerTailnet and network config
Broker virtual keyWhat the caller spends and runsBroker keys file

Front the broker with Aperture for identity, then lean on keys for spend and model scope. Neither replaces the other.

One Key Per Caller

Give every agent profile and every person a distinct key. The broker stores only the SHA-256 hash of each secret. The plaintext secret appears once, at creation, and is never retrievable afterward. A leaked keys file exposes hashes, not working credentials.

Mint a key with the broker’s key tool:

python -m broker.keys create --label team-example --scope user

The tool prints the secret one time, in the form brk_<id>_<random>. Store it in your agent’s secret manager right away. Command shown as documented usage, untested in this article.

Authentication is generic on failure. An unknown key, a revoked key, an expired key, and a wrong secret all return the same 401, compared in constant time. A blocked caller learns only its key failed, not which reason applied.

The Limits You Set Per Key

Each key carries its own ceilings. The broker enforces them before a request reaches a backend, so an over-budget caller never costs you compute. The table below pairs each limit with the abuse it stops.

LimitWhat it stops
rpmToo many requests per minute from one caller
rpm_burstShort spikes above the steady rate, in GCRA mode
tpmToken floods inside a single minute
max_concurrencyOne caller holding many in-flight slots at once
daily_token_budgetA slow token drain across a day
monthly_token_budgetA slow token drain across a month
daily_cost_usdRunaway spend in a single day
monthly_cost_usdRunaway spend across a month
allowed_modelsA caller reaching a model outside its list
per_modelOne model soaking a key’s entire rate budget
placementData processing outside an allowed location
Tenant budgetsOne team’s keys overspending in aggregate

Rate limits (rpm, tpm, max_concurrency) throttle bursts. Budgets (token and cost, daily and monthly) cap sustained use and reset on their period boundary. The allow-list and placement bound scope rather than volume.

A Keys File, End to End

Define keys in a YAML file the broker reads at startup. The example below shows one rate- and budget-limited user key and one admin key. Every secret value is a placeholder. The real keys.yaml is git-ignored, and only the hash is stored.

keys:
  # Rate- and budget-limited user key. All values are placeholders.
  - id: 1a2b3c4d                 # non-secret lookup id; the secret is brk_<id>_<random>
    label: team-example
    tenant: example-tenant
    scope: user
    secret_sha256: "0000000000000000000000000000000000000000000000000000000000000000"
    enabled: true
    expiry: null                 # ISO "YYYY-MM-DD" or null for never
    limits:
      rpm: 60
      rpm_burst: 10              # GCRA burst; applies with BROKER_RATE_LIMIT_ALGO=gcra
      tpm: 100000
      max_concurrency: 4
      daily_token_budget: 1000000
      monthly_token_budget: 20000000
      daily_cost_usd: 5.0
      monthly_cost_usd: 100.0
      allowed_models: [chat, auto]   # fail-closed; also binds auto's resolved pick
      placement: [local]             # unioned with x-broker-placement; tightens only
      per_model:
        chat: { rpm: 30, tpm: 50000 }

  # Admin key, no limits, reads every key's usage. Placeholder hash.
  - id: 9f8e7d6c
    label: ops-admin
    scope: admin
    secret_sha256: "1111111111111111111111111111111111111111111111111111111111111111"
    enabled: true

# Aggregate per-tenant budgets, shared by every key with this tenant and
# enforced in addition to per-key budgets. Placeholder values.
tenants:
  example-tenant:
    daily_token_budget: 5000000
    monthly_token_budget: 100000000
    daily_cost_usd: 25.0
    monthly_cost_usd: 400.0

A caller then uses its secret as a bearer token. The broker checks the hash, applies the limits above, and forwards the request only if the key has headroom.

curl https://<broker-host>/v1/chat/completions \
  -H "Authorization: Bearer <USER_KEY>" \
  -H "Content-Type: application/json" \
  -d '{"model":"chat","messages":[{"role":"user","content":"hello"}]}'

On success, the response carries x-ratelimit-* headers so the caller sees its remaining budget. Command shown as documented usage, untested in this article.

What a Blocked Caller Sees

A refused request returns a structured error envelope. Reading it tells you which ceiling tripped and whether a retry helps. There are two distinct 429 cases, and the difference matters.

A rate limit is transient. The caller sent requests too fast, and the Retry-After value is a short number of seconds. The broker returns these headers:

HTTP/1.1 429 Too Many Requests
retry-after: 60
x-ratelimit-limit-requests: 2
x-ratelimit-remaining-requests: 0
x-ratelimit-reset-requests: 60
content-type: application/json

The body names the limit and gives remediation:

{
  "error": {
    "message": "request rate limit of 2/min reached",
    "type": "rate_limit_exceeded",
    "code": "rate_limit_exceeded",
    "param": null,
    "backend": null,
    "model": null,
    "state": null,
    "remediation": "slow down; see Retry-After and x-ratelimit headers"
  }
}

A budget exhaustion is not transient. A daily or monthly token or cost ceiling is spent, and Retry-After holds the seconds to the next UTC reset. The header block is shorter because no per-minute window applies:

HTTP/1.1 429 Too Many Requests
retry-after: 37194
content-type: application/json

The body uses a different type so the caller knows waiting out a minute will not help:

{
  "error": {
    "message": "daily token budget of 1000000 exhausted",
    "type": "insufficient_quota",
    "code": "insufficient_quota",
    "param": null,
    "backend": null,
    "model": null,
    "state": null,
    "remediation": "wait for the daily reset or raise the budget"
  }
}

A request for a model outside the key’s allow-list returns a 403, not a 429, because the fix is a policy change rather than a wait:

{ "error": { "code": "model_not_allowed", "type": "...", "message": "model not in allowed_models" } }

Key Takeaway: rate_limit_exceeded means retry soon. insufficient_quota means the budget period must reset or grow. model_not_allowed means the key is scoped away from the model.

Fail-Closed Model Allow-Lists

The allowed_models list is fail-closed. A caller reaches only the models named on its key. A request for anything else returns 403 model_not_allowed before any backend runs.

The check binds the resolved model, not the requested alias. When a key allows auto, the broker picks a concrete model, then re-checks the pick against the allow-list and against per-model limits at every cascade hop. A caller has no route past its allow-list by requesting auto and hoping the router lands on a model it should not reach.

Scope keys tightly. A coding agent limited to one chat model has a far smaller abuse surface than a key allowed to reach every backend you host.

Cost Budgets Stop Denial of Wallet

Token budgets cap volume. Cost budgets cap spend. The broker tracks per-key cost in integer micro-USD using the pricing in your model registry, and it refuses a call once the daily or monthly cost ceiling is reached. An unpriced model records zero cost, so set pricing on every model you bill against.

Uncontrolled inference spend is OWASP LLM10:2025 Unbounded Consumption , and the financial form of it is Denial of Wallet. Per-key cost budgets are the direct control for it. On a hosted backend they bound your bill. On a local runtime they bound how long your GPU runs for any one caller.

Who Reads Usage

The /usage endpoint is scope-aware. A user key reads only its own counters. An admin key reads every key’s usage, broken down by key. A leaked user key exposes one caller’s numbers, not the whole fleet’s spend.

Keep the admin key out of agent configs. Reserve it for the operator dashboard and billing reconciliation.

Rotating and Revoking Keys

Rotation mints a successor key with a short grace window, so a live agent keeps working during the swap. Rotation only shortens a key’s life, never extends it, and it refuses to resurrect a revoked or expired key, returning 409 key_not_active. To cut a caller off at once, set enabled: false on its key and reload the broker.

Best Practice: Give high-traffic agents a short expiry and rotate on a schedule. A stolen key then ages out on its own even if you miss the theft.

What the Broker Does Not Do

An honest control list names its gaps. The broker’s governance layer has clear edges.

  • It does not stop prompt injection. The broker treats backend and tool output as data, never as control. It does not parse or act on model output. Prompt-injection defense belongs at the agent boundary. The AI agent trust boundaries lesson covers this control.
  • Legacy flat keys stay unlimited. Keys defined through the old BROKER_API_KEYS variable keep working with no budgets and no rate-limit headers, and they are never throttled. Migrate them into the keys file to govern them.
  • It does not keep the host off the internet by itself. The private-edge property comes from Aperture and your network config, not from broker code.
  • It does not log secrets. Only a non-secret id and fingerprint reach the usage log and metrics. Key material never lands in logs, errors, or default traces. This is enforced in code and documented, with no dedicated test in the governance suite.

Common Mistakes

Common Mistake: Sharing one key across every agent. A single leaked or buggy caller then spends the whole budget. Mint a separate key per caller.

Common Mistake: Setting token budgets but no cost budget. A low token count on an expensive model still drains your wallet. Set both.

Common Mistake: Allowing auto on a narrow key and assuming the router stays cheap. Bind the key to the specific models you accept, and add per-model limits.

Common Mistake: Leaving old BROKER_API_KEYS entries in place. They run unlimited and unthrottled. Move them into the keys file.

Common Mistake: Treating the tailnet edge as the whole defense. Aperture controls reach, not spend. A trusted caller with a broad key still overspends without budgets.

Next Steps

You now scope each caller with its own key, read the exact refusal it receives, and decide which ceiling belongs where. Pair this with the agent-side controls handling the risks the broker leaves open.

Continue with Lesson 9: Threat-Model the Stack .
