Automation and Programmability is 10% of the Cisco CCNA (200-301) exam. This module covers how software-defined networking and automation change network management. Modern networking careers increasingly expect these skills, so do not skip them.
Automation reduces manual errors and speeds up changes across many devices. You learn how controllers, APIs, and configuration tools reshape the work.
How Automation Changes Networks
Manual, box-by-box configuration is slow and easy to get wrong. Automation applies consistent changes at scale, enforces standards, and rolls back faster. The trade is an upfront investment in tooling and skills.
| Approach | Configuration | Scale |
|---|---|---|
| Traditional | Per-device CLI | Slow, error-prone |
| Controller-based | Central policy | Fast, consistent |
Controller-Based and Software-Defined Networking
Controller-based networking splits the control plane from the data plane. The controller makes the decisions, and the devices forward traffic.
| Term | Meaning |
|---|---|
| Underlay | Physical network of devices and links |
| Overlay | Virtual network built on top, such as VXLAN |
| Fabric | The combined underlay and overlay system |
| Northbound API | Controller to applications |
| Southbound API | Controller to network devices |
Cisco Catalyst Center provides centralized campus management through policy and automation. Cloud-managed platforms such as Cisco Meraki offer a remote management plane. A device still forwards traffic according to its local capabilities and configuration when management connectivity changes. Compare the reach, credentials, and failure path of each management option before choosing one.
AI and Machine Learning in Operations
Predictive AI learns patterns from past telemetry and flags unusual behavior or likely capacity problems. Generative AI produces summaries or candidate commands from a prompt. A network operator checks the source telemetry, device model, current configuration, and proposed diff before acting. A model’s answer is not a live state check. Record the operator’s approval and the post-change verification separately.
Practice: A monitoring tool flags a rise in interface errors. Predictive analysis identifies the pattern. A generative tool suggests changing duplex. First compare show interfaces output at both ends, then confirm negotiated speed and duplex. Change only after you identify the cause. Save the before and after counters.
REST APIs
A REST API lets software configure and query devices over HTTP. It maps CRUD operations to HTTP verbs.
| CRUD | HTTP verb |
|---|---|
| Create | POST |
| Read | GET |
| Update | PUT or PATCH |
| Delete | DELETE |
A response code of 200 often means the request succeeded, while 401 means the request lacks valid authentication and 404 means the resource was not found. A 201 response often follows resource creation. The body often uses JSON. An API might use a bearer token, API key, or another authentication method. Send credentials through the service’s documented secure method over HTTPS. Do not place tokens in URLs, examples, or version control. A successful HTTP response does not prove the requested network state changed. Read the resource back and verify the device.
JSON Data
JSON stores data as key-value pairs and arrays. You must recognize valid structure on the exam.
{
"device": "R1",
"interfaces": ["g0/0", "g0/1"],
"enabled": true,
"ospf": { "process": 1, "area": 0 }
}
Keys are strings in quotes, values can be strings, numbers, booleans, arrays, or objects, and commas separate items.
Configuration Management Tools
Cisco v1.1 names Ansible and Terraform. Know the difference between applying device configuration and describing managed infrastructure.
| Tool | Model | Agent |
|---|---|---|
| Ansible | Runs tasks from playbooks, often over SSH or network APIs | Usually no agent on a network device |
| Terraform | Describes desired resources through providers and plans changes before applying them | Uses provider APIs and a state file |
Ansible is popular for network work because it is agentless and uses readable YAML playbooks. To learn it hands-on, read the Ansible for beginners guide .
Worked Change Review
A team wants a new VLAN in a lab. Its proposed automation change declares VLAN 20, named GUEST, on two switches.
- Record the intended devices, VLAN ID, name, and maintenance window.
- Review the Ansible task or Terraform plan. Confirm both devices are in scope. Check for unrelated deletions.
- Require a reviewer to approve the proposed change. Keep the plan or playbook revision with the approval.
- Apply the change only in your lab. Run
show vlan briefon both switches and compare the result with the intended state. - Record any mismatch, rollback action, and final state. A successful playbook run without device verification is incomplete evidence.
Self-check: Explain which part of the example is a desired-state description, which part is an API or device operation, and which observed output proves the VLAN exists. Passing work names all three and keeps credentials out of the saved record. Review the Cisco v1.1 release notes to distinguish current objectives from older Puppet and Chef examples.
Lab 6: Read a Local API-Like Resource and Review a Change
The Packet Tracer topology does not expose a stable management REST API. Use a local read-only HTTP exercise to learn the request, response, JSON, and authentication boundary without implying that a network device changed. Save this synthetic file as device.json in a disposable folder:
{"device":"R1","interface":"g0/1","admin_up":true,"errors":0}
From that folder, start python3 -m http.server 8765 --bind 127.0.0.1. In a second terminal run curl -i http://127.0.0.1:8765/device.json. You should see HTTP 200 and the JSON body. Run curl -i http://127.0.0.1:8765/missing.json; expect 404. End the server with Ctrl+C. The local file server has no authentication and no write API. Never expose it to a network or mistake it for a Cisco controller. A 401 from a real API means missing or invalid authentication; stop and check authorized access instead of placing a token in a URL.
Parse the saved JSON with python3 -c 'import json; d=json.load(open("device.json")); print(d["device"], d["errors"])'. Expected output is R1 0. State what admin_up means in the example and what it does not prove. A saved response is a snapshot, not live interface evidence.
For a change-plan exercise, write a desired state VLAN 20 GUEST and compare it with the actual show vlan brief output from your saved Packet Tracer project. List the proposed add, any unrelated deletion, approval owner, rollback, and post-change command. Do not apply a suggested command until the planned device and port are in scope. After an authorized simulator change, run show vlan brief again and keep the before and after outputs.
If Ansible is installed, practice its check mode only against your own local test file. Save this as local-plan.yml:
- name: Review a local VLAN note
hosts: localhost
connection: local
gather_facts: false
tasks:
- name: Record the proposed VLAN
ansible.builtin.copy:
content: "VLAN 20 GUEST\n"
dest: "{{ playbook_dir }}/vlan-plan.txt"
mode: "0644"
Run ansible-playbook -i localhost, local-plan.yml --check --diff. Check mode reports the proposed change without writing the file. In a disposable folder, run the same command without --check to create the note, then run it again. The second run should report no change. Remove the note when done. This tests local file idempotence, not network-device idempotence. If Ansible is unavailable, mark that optional check not run and use the written change plan for the core checkpoint. See
Ansible’s check and diff mode documentation
.
Your checkpoint is two HTTP statuses, parsed JSON output, a reviewed VLAN change plan, and the observed VLAN result. Pass when you distinguish a read response, a proposed configuration, an approved write, and a device read-back. Record which optional parts were not run. The Cisco CCNA v1.1 topics define the exam scope.
