Cisco lists CCNA 200-301 v1.1 through February 2, 2027, with v2.0 starting February 3, 2027. This course follows the six v1.1 domains. Check the official v1.1 topics and current CCNA page before booking. The lessons explain the topics and build one isolated simulated network. Lab results show specific skills; they do not guarantee exam or workplace readiness.

You need basic IP addressing and command-line familiarity. If subnet masks, gateways, or a switch port are new terms, work through Network+ fundamentals first. Set aside six sessions of 60 to 90 minutes plus a final fault exercise. Work only in a simulator or equipment you own and have permission to configure.

Set up Cisco Packet Tracer

  1. Enroll in Cisco Networking Academy’s free Getting Started with Cisco Packet Tracer course. Download Packet Tracer through that authorized route. Do not download device images or .pkt projects from unofficial mirrors.
  2. Start a blank project. In the device palette, place two routers with two Gigabit Ethernet ports, two switches with Fast Ethernet access ports and Gigabit uplinks, two PCs, and one server. The common Packet Tracer router and switch models work for the basic lab. Interface names differ by model, so replace the sample names with the actual names shown in your project.
  3. Use the connection tool to wire the ports in the table. Save ccna-base.pkt. Keep a separate copy after every module so you can reverse a broken configuration.
CableEnd AEnd B
1PC-A FastEthernet0S1 FastEthernet0/1
2PC-B FastEthernet0S2 FastEthernet0/1
3S1 GigabitEthernet0/2S2 GigabitEthernet0/1
4S1 GigabitEthernet0/1R1 GigabitEthernet0/0
5R1 GigabitEthernet0/1R2 GigabitEthernet0/0
6R2 GigabitEthernet0/1SRV1 FastEthernet0

Use this fictional address plan. 192.0.2.0/24, 198.51.100.0/24, and 2001:db8::/32 are documentation ranges, not live internet targets.

SegmentNetworkGateway or node
VLAN 10, PC-A10.10.10.0/24R1 .1, PC-A .10
VLAN 20, PC-B10.10.20.0/24R1 .1, PC-B .10
R1 to R2192.0.2.0/30R1 .1, R2 .2
R2 to SRV1198.51.100.0/24R2 .1, SRV1 .10

Do not configure every feature at once. The Network Access lesson creates VLANs and trunks. IP Connectivity creates R1 subinterfaces, the R1 to R2 link, routes, and OSPF. IP Services adds controlled NAT and services. Keep a screenshot or text record of intended state, command output, a failure injection, the repair, and the final state at every stage.

OrderDomainWeightCheckpoint
1Network Fundamentals20%Address worksheet and frame-path prediction
2Network Access20%VLAN and trunk verification
3IP Connectivity25%Route choice and OSPF neighbor evidence
4IP Services10%NAT, DHCP, NTP, and logging record
5Security Fundamentals15%ACL allow and deny tests
6Automation and Programmability10%Read-only JSON and reviewed change plan

Packet Tracer models a subset of production features. When a device lacks a feature, study its syntax and use a supplied output example. Label the task simulated or not run. Never claim a simulator proves live wireless controller, VPN, API, or automation behavior.

Final practical assessment

Save a clean copy. Ask another person to insert one fault, or insert the following yourself and hide the answer until diagnosis: change S2’s trunk native VLAN, shut R1’s link to R2, or place a deny ACL before an intended permit. For each fault, record the baseline, symptom, affected path, two candidate causes, the command or packet test, the observed result, one correction, and the restored result. Then restore the clean project.

Pass when PC-A reaches its default gateway, PC-B reaches its default gateway, an allowed PC reaches SRV1, a denied flow fails for the intended ACL reason, and the evidence points to the actual fault rather than a guess. Explain what your simulator did not verify. Review the Cisco CCNA practice test and the official exam topics for theory gaps.

For an exam date on or after February 3, 2027, use Cisco’s v2.0 topics and rebuild your study checklist for that blueprint. Browse the course index for related paths.
