Proxmox VE 8 to 9 Upgrade Guide: In-Place Upgrade with Automated Script

Proxmox VE 9 is based on Debian 13 Trixie and ships with kernel 6.14, QEMU 10, LXC 6, and ZFS 2.3. This guide covers both the manual in-place upgrade path and an automated bash script that detects your configuration and handles every repository change, known issue, and pre-flight check.

What Is New in Proxmox VE 9 #

Proxmox VE 9 (released August 2025) is a major version upgrade. Key changes:

Major new features in PVE 9.0+ include:

• VM snapshots on thick-provisioned LVM via volume chains (tech preview → production in 9.1)
• High-Availability affinity rules replacing HA groups
• SDN Fabrics for OpenFabric and OSPF full-mesh Ceph networks
• New mobile web interface (Rust/Yew)
• ZFS RAIDZ device expansion without downtime
• Dynamic load balancing with the Cluster Resource Scheduler (PVE 9.2)
• WireGuard and BGP as SDN fabric protocols (PVE 9.2)
• /tmp is now a tmpfs (Debian Trixie change — files cleaned periodically)

Before You Start: Prerequisites #

You must satisfy all of these before touching repositories. See the full prerequisites checklist on the official upgrade wiki — Prerequisites .

1. Proxmox VE 8.4 minimum #

pveversion

Output must show pve-manager/8.4.x or higher. If not:

apt update && apt dist-upgrade

2. Ceph must be at Squid (19.x) — hyper-converged only #

ceph --version

Output must show version 19.x (Squid). If you are on Reef (18.x) or Quincy (17.x), upgrade Ceph first. The upgrade path is always one step at a time:

• Quincy (17) → Reef (18) → Squid (19)

Do not proceed to the PVE 9 upgrade until all Ceph nodes are on Squid.

3. Co-installed Proxmox Backup Server #

If PBS is installed on the same node, upgrade PBS 3 → 4 before touching the PVE repositories. Run pbs3to4 --full and resolve all issues first.

4. Access requirements #

• Preferred: console access via IPMI, iKVM, or physical keyboard — the SSH session will drop when services restart
• SSH: use tmux or screen so the upgrade continues if the connection drops:

  tmux new -s upgrade


5. Disk space #

df -h /

Need at least 5 GB free, ideally 10+ GB.

6. Valid backups #

Back up all VMs and containers to external storage before proceeding. Test a restore. A valid backup is not optional.

Breaking Changes You Must Know #

Read these before upgrading. Several require action before or after the upgrade.

cgroup V1 Is Gone #

PVE 9 does not support the legacy cgroupv1 environment at all. If you previously enabled it:

grep -E 'cgroup_no_v1|systemd.unified_cgroup_hierarchy=0' /proc/cmdline

If that returns anything, remove the kernel parameter from /etc/default/grub and run update-grub before upgrading.

Impact on containers: Containers running systemd 230 or older (CentOS 7, Ubuntu 16.04) will not start under PVE 9. Migrate those workloads during the PVE 8 support window (EOL July 2026).

HA Groups Deprecated #

HA groups are replaced by HA rules. They migrate automatically once all cluster nodes are on PVE 9. No manual action required, but verify after upgrading the last node.

VM.Monitor Privilege Removed #

Custom roles that referenced VM.Monitor need updating. Use Sys.Audit for basic KVM monitor access instead. The pve8to9 script detects affected roles.

New Privilege: VM.Replicate #

Creating or editing storage replication jobs now requires VM.Replicate on /vms/<vmid>. Adjust custom roles if needed.

Privileged LXC Containers Require Sys.Modify #

Creating new privileged containers now requires Sys.Modify. Restoring an existing privileged container in-place does not.

systemd-sysctl No Longer Reads /etc/sysctl.conf #

Any custom settings in /etc/sysctl.conf will be silently ignored after the upgrade. Migrate them to /etc/sysctl.d/<NN>-name.conf before rebooting.

# Check what's in sysctl.conf
grep -v '^\s*#\|^\s*$' /etc/sysctl.conf

/tmp Is Now tmpfs #

Debian Trixie mounts /tmp as tmpfs (up to 50% of RAM). Files are cleaned periodically while the system runs. If you use /tmp for large temporary files, move that work to /var/tmp or a dedicated mount.

Veeam Backup Broken for QEMU Machine Version ≥ 10.0 #

Proxmox changed how disks attach to QEMU internally for machine version 10.0+. Veeam has not adapted yet. Either pin affected VMs to machine version 9.2+pve1 before upgrading, or postpone the upgrade if Veeam is critical.

Network Interface Names May Change #

Kernel 6.14 recognizes more NIC features than 6.8. Some NICs pick up additional naming suffixes. The pve-network-interface-pinning tool can pin all interfaces to stable nicX names before the upgrade:

pve-network-interface-pinning --help

Option A: Manual In-Place Upgrade #

Follow the official steps from pve.proxmox.com/wiki/Upgrade_from_8_to_9 .

Step 1: Run the pve8to9 checklist #

pve8to9 --full

Resolve every FAIL item before continuing. Re-run after each fix.

Step 2: Migrate away running VMs (if in a cluster) #

qm migrate <vmid> <target-node>
pct migrate <ctid> <target-node>

Step 3: Fully update PVE 8 #

apt update && apt dist-upgrade
pveversion   # must show 8.4.1 or newer

Step 4: Update Debian base repositories #

sed -i 's/bookworm/trixie/g' /etc/apt/sources.list
sed -i 's/bookworm/trixie/g' /etc/apt/sources.list.d/pve-enterprise.list

Comment out or remove any remaining Bookworm-specific repo lines.

Step 5: Add PVE 9 package repository #

Enterprise (subscription required):

cat > /etc/apt/sources.list.d/pve-enterprise.sources << EOF
Types: deb
URIs: https://enterprise.proxmox.com/debian/pve
Suites: trixie
Components: pve-enterprise
Signed-By: /usr/share/keyrings/proxmox-archive-keyring.gpg
EOF

No-subscription:

cat > /etc/apt/sources.list.d/proxmox.sources << EOF
Types: deb
URIs: http://download.proxmox.com/debian/pve
Suites: trixie
Components: pve-no-subscription
Signed-By: /usr/share/keyrings/proxmox-archive-keyring.gpg
EOF

Verify with apt update && apt policy that the new repo appears without errors. Then remove or comment out the old .list file.

Step 6: Update Ceph repository (hyper-converged only) #

cat > /etc/apt/sources.list.d/ceph.sources << EOF
Types: deb
URIs: https://enterprise.proxmox.com/debian/ceph-squid
Suites: trixie
Components: enterprise
Signed-By: /usr/share/keyrings/proxmox-archive-keyring.gpg
EOF

Use http://download.proxmox.com/debian/ceph-squid with pve-no-subscription for no-subscription setups.

Step 7: Refresh package index #

apt update

Verify no errors.

Step 8: Run the dist-upgrade #

apt dist-upgrade

This takes 5–60+ minutes depending on storage speed. During the upgrade:

• /etc/issue: keep your current version (safe)
• /etc/lvm/lvm.conf: install maintainer version (recommended)
• /etc/ssh/sshd_config: install maintainer version if you haven’t customized it
• /etc/default/grub: keep your current version if you’ve customized it
• /etc/chrony/chrony.conf: install maintainer version if uncustomized

Step 9: Reboot #

reboot

Even if kernel 6.14 was already installed as an opt-in on PVE 8, reboot is required — the kernel is rebuilt with PVE 9 toolchains.

Step 10: Post-upgrade steps #

# Empty browser cache: Ctrl+Shift+R (or ⌘+Alt+R on macOS)
# Verify all nodes in cluster:
pvesh get /nodes

# For clusters: HA groups auto-migrate to HA rules after all nodes are on PVE 9
journalctl -eu pve-ha-crm  # check for errors

Option B: Automated Script (pve8to9-upgrade.sh) #

The manual process has many conditional steps that vary by configuration. The pve8to9-upgrade.sh script automates all of them.

Script source: gist.github.com/simeononsecurity/ba3831f487c4e960f9e218c7da5c4b8d

What the Script Does #

The script handles the full upgrade automatically, including:

All changes are fully logged to /var/log/pve8to9-upgrade-<timestamp>.log. APT repo backups are written to /root/pve8to9-apt-backups/ — never copied as .bak inside /etc/apt/sources.list.d/ (which would cause “invalid extension” errors in the web UI).

Installation and Usage #

# Download the script
curl -fsSL https://gist.githubusercontent.com/simeononsecurity/ba3831f487c4e960f9e218c7da5c4b8d/raw/pve8to9-upgrade.sh \
  -o pve8to9-upgrade.sh

# Make executable
chmod +x pve8to9-upgrade.sh

# Review it before running (always read scripts before executing as root)
less pve8to9-upgrade.sh

Run modes:

# Full interactive mode (recommended)
./pve8to9-upgrade.sh

# Auto-approve all safe, non-destructive fixes
./pve8to9-upgrade.sh --yes

# Dry run: show every change without applying anything
./pve8to9-upgrade.sh --dry-run

# Skip the pve8to9 --full pre-flight (not recommended)
./pve8to9-upgrade.sh --skip-preflight

Run inside tmux or screen if connecting via SSH.

What the Script Output Looks Like #

The script provides a configuration summary before asking you to proceed:

══════════════════════════════════════════
  SUMMARY of detected configuration
══════════════════════════════════════════

  PVE version      : pve-manager/8.4.3/...
  Debian           : bookworm
  Subscription     : true (status: Active)
  PVE repo type    : enterprise  (enterprise was active: true)
  Ceph             : YES (v19.2.3, enterprise repos)
  ZFS root         : false
  UEFI boot        : true
  LVM root         : true
  NVIDIA           : NO
  CUDA repos       : NO
  systemd-boot     : meta=true efi=true
  sysctl.conf      : custom=false (0 lines)
  cgroupv1         : false (must be false for PVE 9)
  FRR post-up      : false (broken pattern)
  LVM autoact.     : false
  PBS co-install   : NO
  3rd-party bookwm : none

The Script’s Blocking Safety Checks #

The script will refuse to continue if any of these conditions are true:

• cgroup V1 is explicitly enabled in the kernel cmdline
• Ceph is still at Quincy (17.x) or Reef (18.x) — shows the exact Ceph upgrade commands
• NVIDIA vGPU driver is below version 570 (GRID 18.3)
• PVE version is below 8.4

For each blocking issue, the script prints the exact commands to resolve it before re-running.

Known Upgrade Issues #

GRUB Fails to Boot from LVM in UEFI Mode #

Affects: Systems with root on LVM, booting in UEFI mode, upgraded from PVE 7.x

# Fix (run on the live system after upgrade):
[ -d /sys/firmware/efi ] && apt install grub-efi-amd64

The pve8to9-upgrade.sh script detects UEFI+LVM and installs this automatically. It also writes a recovery cheat-sheet to /root/GRUB-RECOVERY-CHEATSHEET.txt.

If the node is already stuck at grub rescue> or “disk ’lvmid/…’ not found”:

1. Boot the PVE ISO → Advanced → Rescue Boot
2. Or follow the Recover From Grub Failure — LVM section on the official wiki

systemd-boot Meta-Package Aborts dist-upgrade #

The systemd-boot meta-package was auto-installed on all PVE 8.1–8.4 ISO systems. In Trixie, it contains hooks that fire when other packages upgrade and can abort dist-upgrade mid-run if the ESP is not mounted (Debian Bug #1110177).

# Remove it before the dist-upgrade:
apt remove systemd-boot
# Do NOT remove systemd-boot-efi or systemd-boot-tools — those stay

The pve8to9-upgrade.sh script handles this automatically and explains why in detail.

PCI Passthrough Sometimes Broken with Kernel 6.14 #

Some users report VMs with PCI passthrough fail to start with kernel 6.14. If affected:

# Pin the old kernel temporarily:
proxmox-boot-tool kernel pin 6.8.12-4-pve

Ceph Full Mesh Setups Deadlock on Reboot #

If your /etc/network/interfaces contains:

post-up /usr/bin/systemctl restart frr.service

Change it to:

post-up /usr/bin/systemctl is-active --quiet frr.service && /usr/bin/systemctl restart frr.service || true

Do this before rebooting. The script auto-detects and fixes this pattern.

LVM Thin Pool Needs Repair #

On some systems after upgrade:

Check of pool pve/data failed (status:64). Manual repair required!

Fix:

lvconvert --repair pve/data

NVIDIA vGPU Minimum Driver Version #

Must be at least driver 570.158.02 (GRID 18.3) before upgrading — older drivers are incompatible with kernel 6.x.

nvidia-smi --query-gpu=driver_version --format=csv,noheader

Cluster Upgrade Order #

Upgrade nodes one at a time. Verify each node is healthy before starting the next.

# Check cluster health before each node upgrade:
pvecm status
ceph -s   # if Ceph is deployed

Migration rules during partial upgrades:

• VM/CT from PVE 8 → PVE 9: always works
• VM/CT from PVE 9 → PVE 8: generally not supported

After all nodes are on PVE 9, HA groups auto-migrate to HA affinity rules. Check for errors:

journalctl -eu pve-ha-crm

Troubleshooting #

Upgrade Gets Stuck / “proxmox-ve would be removed” #

If you see:

W: (pve-apt-hook) You are attempting to remove the meta-package 'proxmox-ve'!

One or more packages can’t be upgraded because a Bookworm repo is still configured. Find stray Bookworm entries:

grep -r 'bookworm' /etc/apt/sources.list /etc/apt/sources.list.d/

Comment them out, then:

apt update && apt dist-upgrade

If partially complete:

apt -f install

Failing to Boot after ZFS Upgrade #

If using ZFS root with legacy BIOS boot, see ZFS: Switch Legacy-Boot to Proxmox Boot Tool . The proxmox-boot-tool must manage boot on ZFS systems — not GRUB directly — to survive ZFS feature upgrades.

Post-Upgrade Checklist #

After rebooting each node:

• Clear browser cache (Ctrl+Shift+R / ⌘+Alt+R)
• pveversion shows 9.x
• uname -r shows 6.14.x or newer
• All VMs and CTs start correctly
• Ceph health: ceph -s shows HEALTH_OK
• If UEFI+LVM: verify grubx64.efi mtime is recent
• If NVIDIA passthrough: test a non-production VM
• Update third-party repos that were commented out during upgrade
• Move any /etc/sysctl.conf custom settings to /etc/sysctl.d/

References #

1. Official: Proxmox VE Upgrade from 8 to 9
2. Official: Upgrade from 8 to 9 — Prerequisites
3. pve8to9-upgrade.sh Automation Script
4. Proxmox VE 9.0 Known Issues (Roadmap)
5. Recover From Grub Failure — LVM “disk not found” error
6. ZFS: Switch Legacy-Boot to Proxmox Boot Tool
7. Ceph Reef to Squid Upgrade Guide
8. Proxmox Network Interface Pinning
9. Debian 13 Trixie Release Notes
